iBoot-PDU – Worldwide Models - 8 Ports
Skip to product information
1 of 6

Product description

SKU: 1530189

  • INPUT: 1 x IEC C14. Supplied with IEC320 C13 to CEE7 Linecord
  • OUTPUT: 8 x IEC C13
  • 10 Amps Total
  • Rack Mount PDU: This 1U rack mount power strip is designed specifically for network racks, making it easy to install and manage i server rooms. Remotely reboot your downed devices with an iBoot-PDU.
  • Sophisticated Automation: This rack mount power strip can monitor critical parameters and take corrective action immediately. Build complex notification and reporting for network faults.
  • Manage Multiple Locations & Outlets: One iBoot PDU can be linked to and manage multiple PDUs, creating a single easy way to manage a cluster with the free iBoot Cloud Service.
  • 1U PDU: This rack mount power strip ensures seamless power distribution unit integration into your setup, enhancing control and accessibility with a clean web browser interface.

In stock (can be backordered)

SKU: 1530191

  • INPUT: 2 x IEC C14. Supplied with IEC320 C13 to CEE7 Linecords
  • OUTPUT: 8 x IEC C13
  • 20 Amps Total
  • Rack Mount PDU: This 1U rack mount power strip is designed specifically for network racks, making it easy to install and manage i server rooms. Remotely reboot your downed devices with an iBoot-PDU.
  • Sophisticated Automation: This rack mount power strip can monitor critical parameters and take corrective action immediately. Build complex notification and reporting for network faults.
  • Manage Multiple Locations & Outlets: One iBoot PDU can be linked to and manage multiple PDUs, creating a single easy way to manage a cluster with the free iBoot Cloud Service.
  • 1U PDU: This rack mount power strip ensures seamless power distribution unit integration into your setup, enhancing control and accessibility with a clean web browser interface.

In stock (can be backordered)

SKU: 1530190

  • New S Series Dual 1G Ethernet Port
  • INPUT: 1 x IEC C14. Supplied with IEC320 C13 to CEE7 Linecord
  • OUTPUT: 8 x IEC C13
  • 10 Amps Total
  • Rack Mount PDU: This 1U rack mount power strip is designed specifically for network racks, making it easy to install and manage i server rooms. Remotely reboot your downed devices with an iBoot-PDU.
  • Sophisticated Automation: This rack mount power strip can monitor critical parameters and take corrective action immediately. Build complex notification and reporting for network faults.
  • Manage Multiple Locations & Outlets: One iBoot PDU can be linked to and manage multiple PDUs, creating a single easy way to manage a cluster with the free iBoot Cloud Service.
  • 1U PDU: This rack mount power strip ensures seamless power distribution unit integration into your setup, enhancing control and accessibility with a clean web browser interface.

In stock (can be backordered)

Not stocked but custom orders available

Call us - Email Us











Call for Price

Out of stock

SKU: 1530193

  • INPUT: 1 x IEC C20. Supplied with IEC320 C19 to CEE7 Linecord
  • OUTPUT: 8 x IEC C13
  • 20 Amps Total
  • Rack Mount PDU: This 1U rack mount power strip is designed specifically for network racks, making it easy to install and manage i server rooms. Remotely reboot your downed devices with an iBoot-PDU.
  • Sophisticated Automation: This rack mount power strip can monitor critical parameters and take corrective action immediately. Build complex notification and reporting for network faults.
  • Manage Multiple Locations & Outlets: One iBoot PDU can be linked to and manage multiple PDUs, creating a single easy way to manage a cluster with the free iBoot Cloud Service.
  • 1U PDU: This rack mount power strip ensures seamless power distribution unit integration into your setup, enhancing control and accessibility with a clean web browser interface.

In stock (can be backordered)

SKU: 1530195

  • INPUT: 2 x IEC C20. Supplied with IEC320 C19 to CEE7 Linecords
  • OUTPUT: 8 x IEC C13
  • 40 Amps Total
  • Rack Mount PDU: This 1U rack mount power strip is designed specifically for network racks, making it easy to install and manage i server rooms. Remotely reboot your downed devices with an iBoot-PDU.
  • Sophisticated Automation: This rack mount power strip can monitor critical parameters and take corrective action immediately. Build complex notification and reporting for network faults.
  • Manage Multiple Locations & Outlets: One iBoot PDU can be linked to and manage multiple PDUs, creating a single easy way to manage a cluster with the free iBoot Cloud Service.
  • 1U PDU: This rack mount power strip ensures seamless power distribution unit integration into your setup, enhancing control and accessibility with a clean web browser interface.

In stock (can be backordered)

Not stocked but custom orders available

Call us - Email Us







Call for Price

Out of stock

Not stocked but custom orders available

Call us - Email Us







Call for Price

Out of stock

iBoot PDU Intelligent Power Distribution

iBoot-PDU – Worldwide Models - 8 Ports

iBoot-PDU – Worldwide Models - 8 Ports

Regular price $580.00 USD
Regular price Sale price $580.00 USD
Sale Sold out
AMP
Ethernet Ports (No switch or switch)
Input line Ports
View full details

Major Project Expertise

If you manage a network with hundreds or thousands of sites, every second of downtime costs you serious amounts of dollars. Our solutions are optimized to help you deploy and manage large scale installations around the world and keep them running with minimal downtime.

TOP FEATURES
  • Simple web browser interface
  • Sophisticated Automation
  • Cloud Manageable
  • Integrated 1G Network Switch – New S Series

Clear Status and Easy Control

Power Distribution Units with clear easy to use web interface. This rack mounted PDU makes it easy to manage A/C power from any location. This is a switched and managed PDU, each outlet is independently controlled.

The web page presents a clear status indication of each outlet, current draw across all inputs and the AutoPing monitoring, if implemented. Multiple PDUs can be managed from a single web page.

Each outlet on this PDU can be individually selected, or multiple outlets can be simultaneously operated. User selectable cycle timer allows single command reboot. Delay timer limits inrush current by staggering power up when multiple devices are simultaneously controlled.

Test – Trigger – Action

Monitor critical parameters and take corrective action immediately. Build complex notification and reporting for environmental, power and network faults. Set trigger points and create sequences of responses to keep your network up and running.

  • AutoPing
  • Temperature with accessory probe
  • Mains Current
  • Mains Voltage
  • Time of Day

Free Single Sign-on Service

SNMP Control Program Batch File.

iBoot Cloud Service (iBCS) allows customers with this PDU to access and control multiple units in multiple locations from a single portal with a single sign-on.

iBCS will not only make using the PDU easier, by consolidating all units into one sign-on and interface, it will also enhance the number of situations where a switched PDU can be deployed.

  • Customers with Dynamic IP addressing to always be able to access their iBoot from any location.
  • Service providers manage multiple customer accounts with diverse security configurations
  • Customers that do not allow in-bound connections to access their iBoots.

Easy Install to Router

Perfect for Existing Installations

Models in the new PDU S Series have a built-in 1 Gig Ethernet Switch Integrated in.

Get the managed power you need without an unnecessary cable run to the wiring closet. PDU S Series models with the integrated 1G network switch make it easy to add managed power to your existing installation. Perfect for digital signage, kiosks and telemetry systems in those hard to reach areas. Putting these managed PDUs in-line between the router and the server makes it easy to test both and reboot automatically.

Don’t get in the car just to push that big red button. iBoot can automatically restart crashed systems or put the power of remote reboot in your hands, wherever you are.

How Much Can You Save?

Discover your true Cost of Downtime and how fast your ROI on iBoot will be.

Learn More about iBoot-PDU – Worldwide Models - 8 Ports

Features of iBoot-PDU – Worldwide Models - 8 Ports

Independently Controllable Outlets

The iBoot-PDU series is designed to provide power distribution and remote power control. Each iBoot-PDU allows four or eight outlets to be independently switched on and off for reboot, energy management and security. The iBoot-PDU has many features to make the management of power distribution simple and cost effective:

Web Browser Control

Simple web browser interface is easy to use and provides complete status information and control of the outlets, and groups

Integrated 1Gig Ethernet Switch

Simplify network wiring and reduce home runs to the router. This two port passive switch makes it easy to add remote power management to existing installations.

Telnet/Serial CLI Control

Telnet and serial access use the same Command Line Interface (CLI) structure and syntax to completely configure the iBoot-PDU, or multiple iBoot-PDUs in a cluster configuration.

Multiple Users

Multiple users can be assigned administrator or user only rights, plus access to specific outlets and groups. Users only see the outlets and groups they are assigned to.

Grouping of Outlets for Simultaneous Management

Multiple outlets, across multiple iBoot-PDUs in clustered configurations can be linked together in named groups and managed together. This allows for example, power cycling all devices of a certain type together.

Multiple iBoot-PDU Cluster Configuration

Additional iBoot-PDUs can be managed from a single unit. One master iBoot-PDU provides the communication to the users and continuously receives status information from the rest of the iBoot-PDUs in the cluster. Groups can be created across multiple PDUs and controlled simultaneously.

Automation

The iBoot-PDU can monitor voltage, current and temperature to provide automatic response to the physical environment. AutoPing testing monitors network elements. Program complex sequences of outlet actions and notifications to respond instantly to out of normal situations. Temperature monitoring requires add-on probe.

Real-Time Event Control

Set automatic power actions based on your schedule. Restart systems every day to reduce memory bloat. Power up resources only when needed for energy management, lifecycle extension or security.

Landline Modem Option

The add-on landline modem supports data calls from terminal devices using the CLI, and direct dial from a tone telephone for simple on/off control when more sophisticated means are not available. Voice modem also allows phone dial tone control with voice response (Basic functions only)

Network Management

Setup and Control functions can be linked to any SNMP v2c compatible manager. The iBoot-PDU MIB is downloadable from the website. Reports to syslog server.

Screenshots of iBoot-PDU – Worldwide Models - 8 Ports

Enlarge

Intuitive Dashboard

The dashboard provides clear status indication of each outlet, current draw across all inputs and alarm trigger status Multiple PDUs can be managed from a single web page. Slect one or more outlets and reboot or switch power.

Enlarge

Powerful Automation

Monitor critical parameters and take corrective action immediately. Build complex notification and reporting for environmental, power and network faults. Set trigger points and create sequences of responses to keep your network up and running.

Enlarge

Advanced AutoPing

The soptisticated AutoPing feature detects downtime in critical systems and automatically reboots whenever needed.

Enlarge

Global View

Multiple PDUs can be managed from a single dashboard. The Global view is a compressed presentation for controlling all the PDUs from a single page.

Specifications of iBoot-PDU – Worldwide Models - 8 Ports

Physical

Height:1U 1.75 in (4.5 cm)
Width:11.0 in (27.94 cm)
Depth:6.00 in (15.25 cm)
Weight:4.5 lbs (2 kg)
Temperature
Operating:0 to 65o C
Storage:-10 to 85o C
Relative Humidity0 to 95% Non-Condensing
Altitude2000m Operating

AC Input

100-240 VAC VAC 10 AMP Models: IEC320 C14 Receptacle 20 AMP Models: IEC320 C20 Receptacle

Network

Single or Dual (S Models) 1G Ethernet Web, Telnet, SNMP, SMTP Port Assignable for Web and Telnet. SSL Security on Web control

USB Ports

4 x USB A ports for accessories, modem, temperature probe, etc. 1 x USB B port for serial port and external battery

Temperature Module Option

USB Dual Temperature Sensors. Sensor 2 on 1m cable.

Landline Modem Option

56Kbps V.92 Global Compliance, Data or Tone Dial (DTMF) control

Switched Outlet

4 or 8 IEC 320 C13 Receptacle 10 Amps Max per Receptacle -C10 Models: 15 Amps Max per Linecord -C20 Models: 20 Amps Max per Linecord

Compliance - Safety

Complies with UL62638-1, 2nd Edition, 2014-12-01 (US), IEC62638-1:2014 EN 62368-1:2014 + A11:2017 Complies with CAN/CSA C22.2 No. 62638-1-14, 2nd Edition, 2014-12-01 (Canada)

Compliance - Emmissions

FCC Part 15 A

ANSI C63.4:2014 & 47 CFR Part 15, Subpart B, Class B

ICES-003:2016 Issue 6, Class B

Compliance - Environmental

RoHS 3 Directive (EU) 2015/863Compliant Rated Pollution Degree 2 (PD 2) for use in business/laboratory environments with only Non-Conductive pollution present
